Empowering Data Centers: Unleashing Performance with the HPE 3.2TB SAS-24Gbps Mixed Use SSD for ProLiant Gen10 Plus Servers

Empowering Data Centers: Unleashing Performance with the HPE 3.2TB SAS-24Gbps Mixed Use SSD for ProLiant Gen10 Plus Servers

Introduction

In today’s data-driven enterprise environments, high-performance storage solutions are critical for optimizing server performance and ensuring reliable data access. The HPE 3.2TB 2.5inch SFF Digitally Signed Firmware SAS-24Gbps Basic Carrier Mixed Use Multi Vendor Solid State Drive (SSD) is engineered to meet the demanding needs of modern data centers. Designed specifically for HPE ProLiant Generation10 Plus servers, this SSD combines high capacity, exceptional speed, and robust security features to support mission-critical applications. This article explores the key features, technical specifications, benefits, and compatibility of this advanced storage solution.

Key Features

The HPE 3.2TB SAS-24Gbps SSD is packed with features that make it an ideal choice for enterprises requiring high performance and reliability.

Feature Highlights

High Capacity: Offers 3.2TB of storage, providing ample space for large datasets, databases, and virtualized environments.

SAS-24Gbps Interface: Utilizes a high-speed Serial Attached SCSI (SAS) interface with a 24Gbps transfer rate, delivering superior performance compared to SATA SSDs.

Mixed Use (MU) Workload: Optimized for applications requiring a balanced mix of read and write operations, such as big data analytics, virtualization, and transactional databases.

Digitally Signed Firmware (DS): Enhances security by ensuring firmware authenticity, protecting against unauthorized access and firmware tampering.

Hot-Pluggable Design: Supports seamless drive replacement without powering down the server, minimizing downtime.

HPE Basic Carrier (BC): Simplifies installation and maintenance with a standardized carrier design.

Triple-Level Cell (TLC) NAND Flash: Provides a balance of performance, endurance, and cost-effectiveness for enterprise workloads.

HPE SmartSSD Wear Gauge: Monitors drive health and lifespan, enabling proactive maintenance to prevent data loss.

Technical Specifications

The HPE 3.2TB SSD is designed to deliver exceptional performance and reliability.

Specification Details

Device Type: Solid State Drive (SSD) – Hot-Swap

Capacity: 3.2TB

Form Factor: 2.5-inch Small Form Factor (SFF)

Interface: SAS 24Gbps (dual-port connectivity)

NAND Flash Memory Type: Triple-Level Cell (TLC)

Plug Type: Hot-Pluggable

Carrier Type: Basic Carrier (BC)

Workload Type: Mixed Use (MU)

Height: 15.00 mm

Endurance:

Lifetime Writes: 17,121TB

Drive Writes Per Day (DWPD): 3

Performance:

Drive Transfer Rate: 24Gbps (external)

Maximum Sequential Read Throughput: 2,030 MiB/s

Maximum Sequential Write Throughput: 1,950 MiB/s

Random Read Average Latency (4KiB, Q1): 97 µs

Random Write Average Latency (4KiB, Q1): 29 µs

Random Read IOPS (4KiB, Q=16): 145,000

Random Write IOPS (4KiB, Q=16): 160,000

Maximum Random Read IOPS (4KiB): 155,000 @ Q64

Maximum Random Write IOPS (4KiB): 160,000 @ Q16

Interfaces: 1 x SAS 24Gb/s

Compatible Bay: 2.5-inch SFF

Platform Supported: HPE ProLiant Rack Servers (Generation10 Plus)

Benefits of the HPE 3.2TB SAS-24Gbps SSD

The HPE 3.2TB SAS-24Gbps SSD offers several advantages that make it a standout choice for enterprise storage needs.

High Performance for Mixed Workloads

The SSD is designed for mixed-use workloads, offering balanced performance for applications requiring both high read and write IOPS. With sequential read and write throughputs of up to 2,030 MiB/s and 1,950 MiB/s, respectively, and random IOPS performance of up to 155,000 for reads and 160,000 for writes, this SSD excels in environments like big data analytics, high-performance computing (HPC), and virtualization.

Enhanced Data Security

The digitally signed firmware ensures that the drive’s firmware comes from a trusted source, preventing unauthorized modifications that could compromise data integrity or system security. This feature is critical for enterprises handling sensitive data, such as financial institutions or healthcare organizations.

Superior Reliability and Endurance

Backed by over 3.35 million hours of testing and qualification, HPE SSDs are built for 24x7 operation in enterprise data centers. With an endurance rating of 17,121TB written and a DWPD of 3, this SSD is designed to handle demanding workloads over its lifespan. The HPE SmartSSD Wear Gauge further enhances reliability by allowing administrators to monitor drive health and predict potential failures.

Cost-Effective Performance

Compared to SATA SSDs, the HPE SAS-24Gbps SSD delivers roughly twice the IOPS performance, making it a cost-effective solution for enterprises seeking to improve transactional database workloads without breaking the budget. The multi-vendor SKU offering ensures competitive pricing and availability.

Seamless Integration and Maintenance

The hot-pluggable design and HPE Basic Carrier simplify installation and maintenance, reducing downtime during drive replacements. The “do not remove” button on the carrier prevents accidental drive removal, further protecting data integrity.

Compatibility with HPE ProLiant Gen10 Plus Servers

The HPE 3.2TB SAS-24Gbps SSD is specifically designed for HPE ProLiant Generation10 Plus servers, ensuring seamless compatibility and optimal performance.

Supported Server Models

The SSD is compatible with the following server models (all supporting 2.5-inch SFF drives):

HPE ProLiant DL Series:

DL20 Gen10 Plus (Base, Entry, High Performance, Performance)

DL325 Gen10 Plus V2 (Base, Performance, for Weka Base Tracking)

DL345 Gen10 Plus (Base, Entry)

DL360 Gen10 Plus (All-NVMe Server for Software Defined Storage, for SAP HANA Compute Block, for Weka Base Tracking, Network Choice)

DL380 Gen10 Plus (Network Choice)

DL385 Gen10 Plus V2 (Base, Entry)

This SSD is ideal for a variety of workloads, including read caching, web servers, virtualization, and mission-critical applications requiring high availability and data integrity.

Use Cases

The HPE 3.2TB SAS-24Gbps SSD is well-suited for a range of enterprise applications.

Application Scenarios

Big Data Analytics: High IOPS and low latency make it ideal for processing large datasets in real-time.

Virtualization: Supports virtualized environments with balanced read and write performance, ensuring smooth operation of virtual machines.

Transactional Databases: Delivers fast access to data for applications like financial systems, e-commerce platforms, and customer relationship management (CRM) systems.

High-Performance Computing (HPC): Provides the speed and endurance needed for compute-intensive workloads in scientific research and simulations.

Comparison with Other Storage Solutions

The HPE 3.2TB SAS-24Gbps SSD offers distinct advantages when compared to other storage solutions.

SAS vs. SATA and NVMe

When compared to SATA SSDs, the HPE SAS-24Gbps SSD provides significantly higher performance and reliability. SATA SSDs, with transfer rates up to 6Gbps, are suited for general-purpose workloads but fall short in IOPS and speed compared to SAS-24Gbps. The SAS interface, with dual-port connectivity and full-duplex data transfer, delivers superior performance for enterprise applications. Compared to NVMe SSDs, which offer ultra-low latency via PCIe, the SAS-24Gbps SSD provides a cost-effective balance of performance and compatibility for environments that do not require NVMe’s extreme speeds.

Ordering Information

The HPE 3.2TB SAS-24Gbps SSD is available through multiple part numbers to suit various procurement needs.

Part Numbers

P49053-B21

P49053-H21

P49053-K21

P49053-X21

P49749-001

Conclusion

The HPE 3.2TB 2.5inch SFF Digitally Signed Firmware SAS-24Gbps Basic Carrier Mixed Use Multi Vendor Solid State Drive is a high-performance, reliable, and secure storage solution tailored for HPE ProLiant Generation10 Plus servers. With its robust feature set, including a high-speed SAS-24Gbps interface, digitally signed firmware, and mixed-use optimization, this SSD is an excellent choice for enterprises seeking to enhance their data center performance. Whether powering big data analytics, virtualization, or transactional databases, this SSD delivers the speed, endurance, and security needed to meet the demands of modern IT environments.

For organizations looking to upgrade their storage infrastructure, the HPE 3.2TB SAS-24Gbps SSD offers a compelling combination of performance, reliability, and value, making it a cornerstone for next-generation enterprise workloads.

May 22nd 2025 Mike Anderson
