HPE 727055-B21 10GbE 2-Port 562SFP+ Network Adapter for G9 G10 Servers

SKU:
727055-B21
UPC:
00088775838349
MPN:
727055-B21
Condition:
New
Availability:
In Stock - Ship Same Day
  • HPE 727055-B21 Ethernet 10Gb Dual Port PCI-Express 3.0 x8 562SFP+ Network Adapter for ProLiant Gen9 Gen10 Servers (Brand New with 3 Years Warranty)
  • HPE 727055-B21 Ethernet 10Gb Dual Port PCI-Express 3.0 x8 562SFP+ Network Adapter for ProLiant Gen9 Gen10 Servers (Brand New with 3 Years Warranty)
  • HPE 727055-B21 Ethernet 10Gb Dual Port PCI-Express 3.0 x8 562SFP+ Network Adapter for ProLiant Gen9 Gen10 Servers (Brand New with 3 Years Warranty)
$299.95
Frequently bought together:

Description

HPE 727055-B21 Ethernet 10Gb Dual Port PCI-Express 3.0 x8 562SFP+ Network Adapter for ProLiant Gen9 Gen10 Servers (Brand New with 3 Years Warranty)

This 10GbE Dual Port 562SFP+ Adapter is part of an extended catalog of products tailored for customers in specific markets or with specific workloads, requiring the utmost in performance or value, but typically have a longer lead-time.

The HPE Ethernet 10Gb 2-port 562SFP+ Adapter features the latest Intel controller. It is a low-cost, low-power dual port PCIe v3.0 x8 adapter designed for HPE ProLiant servers. The HPE 562SFP+ addresses the demanding needs of the next-generation data center by providing unmatched features for virtualization and scalability that complement the HPE server platform.

The HPE 562SFP+ comes with both low profile and standard brackets and has two SFP+ cages that enable connections with DACs as well as SR fiber optic modules. The HPE 562SFP+ adapter supports SR-IOV and high performance networking features such as VLAN tagging, low latency interrupts, TCP and UDP checksum offloading, MSI-X, NIC teaming (bonding), Receive Side Scaling (RSS), jumbo frames, and PXE boot.

Outstanding I/O Performance in Virtualized Server Environments
Reduces I/O bottlenecks by providing intelligent offloads for networking traffic per virtual machine (VM), enabling near-native performance and VM scalability.
The single-root I/O virtualization (SR-IOV) allows an I/O device to be shared by multiple Virtual Machines (VMs), without losing runtime performance.
Dual-port PCIe 3.0,x8 lane 10Gb, designed for HPE ProLiant Gen9 Rack/Tower and Density.
Data Plane Developer Kit (DPDK) optimized for efficient packet processing.

Network Virtualization is the Next Big Trend in Creating an Agile Data Center
Provides stateless offloads that preserve application performance for overlay networks. With these offloads it is possible to distribute network traffic across CPU cores.
VXLAN and NVGRE Offloads for stateless offloads preserves application performance for overlay networks and makes it possible to distribute network traffic across CPU cores.
Excellent small packet performance for network appliances and Network Function Virtualization (NFV).
Optimized servers providing up to 40Gb/s bi-directional near line rate throughput.

The HPE 727055-B21 Ethernet 10Gb Dual Port 562SFP+ Network Adapter have dual interface SFP+ ports to connect desktop and server systems to the network. The 727055-B21 10GbE Dual Port 562SFP+ Network Card includes Wake on LAN (WOL), PXE support. This 10GbE 2-port 562SFP+ Network Adapter comes with 3 Years Warranty.

Specifications

Brand: HPE
MPN: 727055-B21

Option Part Number: 727055-B21
Spare Part Number: 790316-001

General

Device Type: Network adapter
Form Factor: Standard and low profile adapter compliant with the PCIe standard
Interface (Bus) Type: PCI Express 3.0 at 8 GT/s x8

Networking

Network Processor: Intel® X710 Controller
Ports: 10 Gigabit SFP+ x 2
Connectivity Technology: Wired
Data Link Protocol: 10 GigE
Data Rate: Two ports, each at 20 Gb/s bi-directional; 40 Gb/s aggregate bi-directional theoretical bandwidth.
Capacity: Jumbo frame size:9.5 KB
Status Indicators: Status, link/activity
Features: Wake on LAN (WOL), PXE support
IEEE Compliance: 802.3, 802.1ab, 802.3x, 802.3ad, 802.3p, 802.1q, 802.3ae, 802.1au, 802.3ap, 802.1as, 802.3ak,802.1qaz, 802.1Qbb

Processor / Memory

Processor: 1 (Intel® X710 Controller)
Onboard Memory: 256 MB

Expansion & Connectivity

Interfaces: 2 x 10Gb Ethernet - SFP+

Power Specification

Typical Power Consumption: 10.00 Watt
Maximum Power Consumption: 10.80 Watt

Environmental Parameters

Min Operating Temperature: 32 °F (0 °C)
Max Operating Temperature: 131 °F (55 °C)
Operating Humidity Range: 5 - 95% (non-condensing)
Emissions Classification: Class B

Miscellaneous

RoHS Compliance: 5 of 6
Safety Standard: UL Mark (USA and Canada), CE Mark, EN 605901 2nd edition

Agency Approvals

USA: FCC Part 15 Class B
Canada: ICES-003, Issue 5
Japan: VCCI 2011-04 Class B
International: EN55022:2010 + Class B, EN55024:2010, EN61000-3-2:2006, EN61000-3-3:2008
Taiwan: BSMI, CNS13438 (2006) Class B
Australia/New Zealand (AS/NZS): AS/NZS CISPR 22: 2009+A1:2010 Class
Korea: KN22 Class B, KN24

Software / System Requirements

OS Required: SuSE Linux Enterprise Server 11, Microsoft Windows Server 2008 R2, SuSE Linux Enterprise Server 10, Microsoft Windows Server 2008, Microsoft Windows HPC Server 2008, Red Hat Enterprise Linux 6, Red Hat Enterprise Linux 5.x, Oracle Solaris 10, VMware ESX 4.1, VMware ESXi 4.1, Microsoft Windows Server 2012

Compatibility Information

Designed for

HPE ProLiant DL Series: DL20 Gen10, DL20 Gen10 Entry, DL20 Gen10 Performance, DL20 Gen10 solution, DL60 Gen9, DL80 Gen9, DL80 Gen9 Entry, DL120 Gen9, DL160 Gen9, DL180 Gen9, DL180 Gen9 Base, DL180 Gen9 Entry, DL180 Gen9 Storage, DL360 Gen9, DL360 Gen10, DL360 Gen10 Base, DL360 Gen10 Entry, DL360 Gen10 High Performance, DL360 Gen10 Low, DL360 Gen10 Performance, DL360 Gen10 Solution, DL380 Gen9, DL380 Gen10, DL380 Gen10 Base, DL380 Gen10 Entry, DL380 Gen10 High Performance, DL380 Gen10 Performance, DL380 Gen10 Solution, DL385 Gen10, DL560 Gen9, DL560 Gen10, DL560 Gen10 Base, DL560 Gen10 Entry, DL560 Gen10 Performance, DL580 Gen9, DL580 Gen10, DL580 Gen10 Base, DL580 Gen10 Entry, DL580 Gen10 Performance Servers

HPE ProLiant ML Series: ML30 Gen10, ML30 Gen10 Entry, ML30 Gen10 Performance, ML30 Gen10 Solution, ML110 Gen9, ML110 Gen9 Base, ML110 Gen9 Entry, ML110 Gen10, ML110 Gen10 Performance, ML110 Gen10 Solution, ML150 Gen9, ML350 Gen9, ML350 Gen10, ML350 Gen10 Base, ML350 Gen10 Entry, ML350 Gen10 Performance, ML350 Gen10 Solution, ML350 Gen10 Sub-Entry Servers

HPE ProLiant XL Series: XL230a Gen9 NHP Compute Tray (12G), XL230k Gen10 Compute Tray, XL270d Gen9, XL450 Gen10 Servers

HPE Apollo 2000 Series: XL170r Gen9, 2000 XL190r Gen9 Servers

HPE Apollo 4200 Gen9 Server

HPE Apollo 4500 XL450 Gen9 Server

HPE Apollo 6000 Series: XL230a Gen9, XL250a Gen9, XL260a Gen9, XL270d Gen9 Servers

HPE Apollo 6500 XL270d Gen10 Server

HPE StoreEasy: 1450, 1850, 3850 Gateway Single Node

Standard Features

Throughput-Theoretical Bandwidth
This adapter delivers 20 Gb/s bi-directional Ethernet transfer rate per port (40 Gb/s per adapter), providing the network performance needed to improve response times and alleviate bottlenecks.

802.1Q VLANs
IEEE 802.1Q virtual local area network (VLAN) protocol allows each physical port of this adapter to be separated into multiple virtual NICs for added network segmentation and enhanced security and performance.
VLANs increase security by isolating traffic between users. Limiting the broadcast traffic to within the same VLAN domain also improves performance.

Checksum & Segmentation Offload
Normally the TCP Checksum is computed by the protocol stack. Segmentation Offload is technique for increasing outbound throughput of high-bandwidth network connections by reducing CPU overhead. The technique is also called TCP segmentation offload (TSO) when applied to TCP, or generic segmentation offload (GSO).

Configuration Utilities
This adapter ships with a suite of operating system-tailored configuration utilities that allow the user to enable initial diagnostics and configure adapter teaming. This includes a patented teaming GUI for Microsoft Windows operating systems. Additionally, support for scripted installations of teams in a Microsoft Windows environment allow for unattended OS installations.

DPDK
This adapter supports DPDK with benefit for packet processing acceleration and use in NFV deployments.

HPE Sea Of Sensors 3D
Support for the HPE Sea of Sensors which is a collection of 32 sensors that automatically track thermal activity - heat - across the server. When temperatures get too high, sensors can initiate fans and make other adjustments to reduce energy usage. A significant improvement lies in the ability to apply fan speed increases only to the portion of the system that is rising in temperature, rather than all six fans in unison, which reduces the amount of energy used for cooling.

IPv6
IPv6 uses 128-bit addressing allowing for more devices and users on the internet. IPv4 supported 32-bit addressing.

Jumbo Frames
This adapter supports Jumbo Frames (also known as extended frames), permitting up to a 9,000 byte (KB) transmission unit (MTU) when running Ethernet I/O traffic. This is over five times the size of a standard 1500-byte Ethernet frame. With Jumbo Frames, networks can achieve higher throughput performance and greater CPU utilization. These attributes are particularly useful for database transfer and tape backup operations.

LED Indicators
LED indicators show link integrity and network activity for easy troubleshooting.

Management Support
This adapter ships with agents that can be managed from HPE Systems Insight Manager or other management application that support SNMP.

Message Signaled Interrupt (Extended) (MSI-X)
Message Signaled Interrupt (Extended) provides performance benefits for multi-core servers by load balancing interrupts between CPUs/cores.

Network Adapter Teaming
This adapter support for NIC teaming helps IT administrators increase network fault tolerance and increased network bandwidth, the team of adapters can work together as a single virtual adapter, providing support for several different types of teaming enabling IT administrators to optimize availability, improve performance and help reduce costs.

Optimized for Virtualization
I/O Virtualization support for VMware NetQueue and Microsoft VMQ helps meet the performance demands of consolidated virtual workloads.

PCI Express Interface
This adapter is designed with an eight lane (x8) PCI Express bus based on the PCIe 3.0 standard. The adapter is backward compatible with four lane (x4) PCI Express, automatically auto-sensing between x8 and x4 slots.

Preboot eXecution Environment (PXE)
Support for PXE enables automatic deployment of computing resources remotely from anywhere. It allows a new or existing server to boot over the network and download software, including the operating system, from a management/ deployment server at another location on the network. Additionally, PXE enables decentralized software distribution and remote troubleshooting and repairs.

Receive Side Scaling (RSS)
RSS resolves the single-processor bottleneck by allowing the receive side network load from a network adapter to be shared across multiple processors. RSS enables packet receive-processing to scale with the number of available processors.

Server Integration
This adapter is a validated, tested, and qualified solution that is optimized for HPE ProLiant servers. Hewlett Packard Enterprise validates a wide variety of major operating systems drivers with the full suite of web-based enterprise management utilities including HPE Intelligent Provisioning and HPE Systems Insight Manager that simplify network management.
This approach provides a more robust and reliable networking solution than offerings from other vendors and provides users with a single point of contact for both their servers and their network adapters.

TCP/UDP/IP
For overall improved system response, this adapter supports standard TCP/IP offloading techniques including: TCP/IP, UDP checksum offload (TCO) moves the TCP and IP checksum offloading from the CPU to the network adapter. Large send offload (LSO) or TCP segmentation offload (TSO) allows the TCP segmentation to be handled by the adapter rather than the CPU.

Precision Time Protocol (IEEE 1588 PTP)
Synchronization of system clocks throughout a network, achieving clock accuracy in the sub-microsecond range, making it suitable for measurement and control systems.

VMware NewQueue and Microsoft Virtual Machine Queue (VMQ)
VMware NetQueue is technology that significantly improves performance of 10 Gigabit Ethernet network adapters in virtualized environments.
Windows Hyper-V VMQ (VMQ) is a feature available on servers running Windows Server 2008 R2 with VMQenabled Ethernet adapters. VMQ uses hardware packet filtering to deliver packet data from an external virtual machine network directly to virtual machines, which reduces the overhead of routing packets and copying them from the management operating system to the virtual machine.

Please contact with us if you have any question or to know the compatibility of this with your current server or storage array.
