HPE P26285-H21 960GB 2.5in DS SAS-24G SC Read Intensive G10 SSD

HPE P26285-H21 960GB 2.5inch Small Form Factor (SFF) Digitally Signed Firmware (DS) SAS-24Gbps Smart Carrier (SC) Read Intensive Solid State Drive for ProLiant Gen10 Servers (New Bulk Pack with 90 Days Warranty)

HPE Server Read Intensive (RI) Solid State Drives (SSDs) deliver high performance and endurance for applications requiring high random read IOPS performance. HPE (RI) SSDs typically have an endurance of <1 drive writes per day. All HPE SSDs are backed by over 3.35 million hours of testing and qualification ensuring reliable, high performing drives. HPE Digitally Signed Firmware prevents unauthorized access to your data by providing the assurance that drive firmware comes from a trusted source. The self-describing icons on the HPE Smart Carrier take the guesswork out of a drive’s status, and a inch do not remove inch button prevents data loss from human error. You can also monitor the lifespan of your SSD with HPE SmartSSD Wear Gauge compatibility in management tools, allowing you to determine if any drives are at risk of failure.

High Performance, Exceptional Reliability, and Efficiency for Faster Business Results
HPE solid-state drives are ideal for big data analytics, cloud computing, active archiving, database applications, and data warehousing.
Achieve higher IOPs to enhance the performance of your data center.
Maintain data accuracy with full data-path error detection.
Choose from a broad portfolio of enhanced solutions in a wide variety of capacities.
12 Gb/s SAS, 6 Gb/s SATA, NVMe, M.2, and M.2 Enablement Kits.

HPE Value SAS SSDs Offer Twice the IOPS of SATA SSDs, Significantly Improving Workload Performance
HPE Value SAS solid-state drives (SSDs) support 12 Gbs, versus SATA SSDs at 6 Gbs.
Optimized for enterprise application workloads, HPE Value SAS SSDs allow you to do more work with fewer servers by improving and consolidating transactional database workloads.
HPE Value SAS SSDs allow you to reduce operating costs for storing, powering and maintaining servers, as well as reducing your data center footprint.
Available in a variety of storage capacities, HPE Value SAS SSDs are the perfect choice for supporting read-intensive and mixed-use applications.

HPE Multi Vendor SSDs Offer Longer SKU Lifecycles and Immediate Availability on SATA SSDs
HPE enhanced its extensive SSD portfolio with a Multi Vendor SSD SKU offering that allows for extended SKU lifecycles, immediately available supply and preferably priced SATA SSDs.
HPE Multi Vendor SSD SKU offering ensures the SATA SSD selected, delivers the minimum level of performance published, or better.

Serial Attached SCSI (SAS) is the logical evolution of SCSI including its long-established software advantage and the serial physical connection interface. With enterprise storage requirements escalating and becoming more complex factors such as larger capacity greater density security scalability and accessibility are more critical than ever. Enterprise data centers must be online all the time fulfill requests from numerous users simultaneously allow for constant growth and expansion and be maintained while in operation. Serial Attached SCSI (SAS) meets all these demands while providing the highest performance.

Smart Carriers
HPE Hard Drives with smart carriers are designed to provide an interface to communicate critical status and management information. System status LED icons and a spinning activity ring reflecting the data-writing process notify users of the current system status. A blue LED located behind the handle can be activated remotely to guide users to a specific drive tray, while a do-not-remove icon positioned on the tray's eject button lights up to warn users when the removal of the drive would cause data loss.

Digitally Signed Firmware: Prevent unauthorized access to your data with the expansion of integrated HPE Digitally Signed Firmware (DS) on new drives; providing the security and assurance that drive firmware comes from a trusted source and protects against malicious attacks.

The HPE P26285-H21 Read Intensive Solid State Drive has a 2.5 inch form factor and a 24 Gbps external data transfer rate. It has a 960 GB capacity. This Small Form Factor Digitally Signed Firmware (DS) solid state drive uses a SAS-24Gbps interface and has 90 Days Warranty.

Specifications

Brand: HPE
MPN: P26285-H21

Option Part Number: P26285-H21
Spare part Number: P37166-001

General

Device Type: Solid State Drive - Hot-Swap
Capacity: 960 GB
Form Factor: 2.5 inch SFF
Interface: SAS 24Gbps
Plug Type: Hot Pluggable
Carrier Type: Smart Carrier (SC)
Connectivity: Dual Port
Workload Type: Read Intensive
Features: Digitally Signed Firmware
NAND Flash Memory Type: Triple-Level Cell (TLC)
Bundled with: HPE Smart Carrier
Platform Supported: HPE ProLiant Rack/Tower/BladeSystem Servers/Synergy
Height: 0.6 inch (15 mm)

Performance

30 Days Writes (TB): 1712
Drive Transfer Rate: 24 Gbps (external)
Endurance DWPD (Drive Writes Per Day): 1
MAX Seq. Reads Throughput (MiB/s): 1080
MAX Seq. Writes Throughput (MiB/s): 1035
Random Read Average Latency uSec (4KiB,Q1): 95
Random Write Average Latency uSec (4KiB,Q1): 32
Random Read IOPS (4KiB, Q=16): 150000
Random Write IOPS (4KiB, Q=16): 75000
MAX Random Read IOPS (4KiB): 173000@Q64
MAX Random Write IOPS (4KiB): 76000@Q4

Expansion & Connectivity

Interfaces: 1 x SAS 24 Gb/s
Compatible Bay: 2.5" SFF

Power Consumption

Idle Time: 2.77 Watt
Random Read: 6.68 Watt
Random Write: 6.68 Watt
Sequential Read: 6.76 Watt
Sequential Write: 8.35 Watt
Random Read/Write: 6.68 Watt
Maximum: 8.35 Watt

Product Dimensions & Weight

Height: 5.75 (14.61 cm)
Width: 8.63 inch (21.92 cm)
Depth: 9.00 inch (22.86 cm)
Weight: 1.10 lbs (0.50 kg)

Compatibility Information

Designed for

HPE D2500sb Storage Blade, D3700, D3710

HPE Apollo 4200 Gen10 (2.5inch), 4200 Gen10 384TB 25Gb Capacity Server for Cohesity DataPlatform (2.5inch), 4200 Gen10 384TB Capacity Server for Cohesity DataPlatform (2.5inch), 4200 Gen10 for HPE Ezmeral Container Platform (2.5inch)

HPE ProLiant XL Series: XL450 Gen10 (2.5inch), XL450 Gen10 200TB Server for Cohesity DataPlatform (2.5inch), XL450 Gen10 400TB Server for Cohesity DataPlatform (2.5inch), XL450 Gen10 700TB Server for Cohesity DataPlatform (2.5inch)

Contact us if you have any question about this product to verify this model’s compatibility with your current server or storage array.
